There are two well established, similar methods for measurement of conductive plastics, here is a short comparison of them. I’ll add pictures of my solutions in due time – if interested, ask for quotation via contact form
- Current electrodes are on both sides of the sample, aligned and connected with a jumper wiring.
- Load between the current electrodes is varied according to the sample width, which is defined as 1 to 15 cm. The applied force is 300 N/m.
- Pointy voltage electrodes are on the bottom side of the sample. Applied force is 60 N/m.
- More streamlined measurement process.
- Sample is fixed to outer electrodes with more leeway in design, not necessarily from both sides.
- Current electrode load is not specified, while the voltage sensing system mass is defined to exert roughly a force of 0,6 N on the sample across the span of 10 ± 0,2 mm.
- More complicated sampling process.
Other literature sources
- OCSiAl has made a good overview of different measurement methods here.
